Manure Rotary Dryer

Brief introduction of manure dryer

A manure dryer is a continuously working equipment to process a large number of manure. The moisture content of manure after drying could reach 10% below (moisture content is adjustable by the control system). Due to the reliable performance, high operation flexibility, wide application, high handling capacity, manure dryer has a good drying effect for chicken manure, cow manure, pig manure, etc. Materials that are dried by manure dryer could be used for fertilizer, and are convenient to transport. It is widely used in agriculture, the chemistry industry, etc. Manure dryer is energy-saving and environment-protecting equipment that not only improves the utilization of waste, reduces environmental pollution, but also creates a good economic benefit and social benefit. Manure dryer produced by us has been in operation worldwide. Companies use dried manure to make organic fertilizer for crops. Manure dryers have been sold to many countries, such as India, Malaysia, the Philippines, Indonesia, Oman, Mexico, etc. Now our drying equipment is running normally, clients speak highly of our manure dryer.

Manure the dryer manufactured by Zhengke has passed the inspection of Henan Quality Supervision Bureau, ISO9001 international quality management system certification, Europe CE certificate standard, Russian GOST certificate, etc. Meanwhile, we had applied many patents of manure dryers to the State Patent Office and were well-known in the drying equipment industry.

Features of Zhengke Manure dryer

1. High drying efficiency, good drying effect. The manure dryer is continuously working drying equipment, used the “feeding at one end and discharging at the other” method for drying manure. Due to the high moisture content, high stickiness of animal manure, we make a special design of the inside structure, manure dryer has high drying efficiency. We could control and adjust the final moisture content to the client's request.

2. Energy-saving, environment-protecting, no pollution, no noise. Zhengke manure dryer could dry cow manure and pig manure, then reuse them. This improves resource utilization and reduces environmental pollution. Due to the special design of mechanical structure and electricity control, the manure dryer works at low power. Also, the manure dryer is equipped with multistage dust collecting equipment to meet the national standard of environment protection. In addition, manure dryer is equipped with deodorization equipment, to ensure that the discharged gas without peculiar smell, it is a kind of good energy conservation and environmental protection equipment. Our manure dryer adopts an enclosed structure; no air pollution and noise pollution will happen during the drying process.

3. Wide application range, low request for the working environment. Zhengke manure dryer is applicable for every country in the world. We could make some adjustments according to the different situations in different countries, such as voltage, engineering design requirement, geographical conditions, etc. As to the working environment, Zhengke manure dryer could work normally in severe cold, high temperature, plateau, etc.

4. Simple installation. Manure dryer could work directly on a horizontal hardened site. In the running, no vibration happens. It is also convenient to transfer and transport the equipment.

5. Few workers, simple operation, easy maintenance. To client request, Zhengke could provide semi-automation and a total automation production line. Only regular maintenance to the instruction is needed. It is very convenient to maintain.

6. High safety. The transmission parts all adopt enclosed or semi-enclosed design to the equipment standard of security, such as transmission shaft, motor, belt pulley, etc. This ensures the safety of equipment and workers.

Technical Parameter of Manure Dryer

Note:The above technical parameters are for reference, can be separately designed according to the customer’s actual situation.

Working principle of manure dryer

Manure dryer is placed at an inclination of 3-5°. Manure is sent to the inlet by feeding device, then spiral feeders push materials into the drum from feeding end to discharge end. Hot air will be drawn into the drum by a draft fan and exchange heat with materials constantly. As the drum rotates, materials are lifted and scattered by lifting boards repeatedly under gravity and move toward the lower end. As manure moves forward, it gets heat directly and indirectly from the heating medium. Thus, manure gets dried and discharged at the outlet. On the inner of the cylinder, lifting boards are equipped to lift materials and scatter them. This would spread the contact surface to improve the drying rate and promote materials to move forward. Usually, a cyclone collector would collect the dust that the heating medium entrains. If you want to reduce dust content further, a baghouse or wet scrubber may be needed.

The main structure and process flow chart of the Manure dryer

1、Furnace；1-1、Gas Stove；2、Materials；3、Feeding Conveyor；4、Inlet；5、Feeding Cover；6、Roller Ring；7、Carrier Roller；8、Drum；9、Transmission；10、Gear Ring；11、Roller Ring；12、Carrier Roller；13、Discharge Cover；14、Dust Collector；15、Chimney；16、Induced Draft Fan；17、Motor；18、Outlet；19、Discharging Conveyor

Kehua Industrial is one of the leading manufacturers and suppliers of high-quality and high-safety manure rotary dryers in China. Our manure rotary dryer products are sold at a cheap price, and our factory has many products in stock. Welcome to buy energy-saving, eco-friendly, and discount equipment with us and check the quotation with us.
